DIP Thru Hole SMT Tact Switch , Momentary Tactile Switch For Industrial Electronics

Name: DIP Thru Hole SMT Tact Switch Momentary Tactile Switch For Industrial Electronics
Brand: BZCN
Price: 1 USD

China DIP Thru Hole SMT Tact Switch , Momentary Tactile Switch For Industrial Electronics wholesale

Brand Name : BZCN

Model Number : TS-C017

Certification : SGS

Place of Origin : CHINA

MOQ : 1000 pcs

Price : Negotiable

Payment Terms : L/C, T/T, Western Union, MoneyGram

Supply Ability : 10000000 pcs per week

Delivery Time : 3 days

Packaging Details : 1000 pcs per bag

Cover : metal

Pin No. : 3 side pins

Rating : 50mA

Voltage : 12v

Terminal : THT/DIP

Push : Vertical

Contact Now

DIP thru hole 3 pin low profile 4.5 mm tactile switch momentary operation

Sealed Tact Switch for SMT is a 2.5mm high switch, designed to give users a positive tactile feeling when used. Perfect for industrial electronics, consumer products, instrumentation or automotive applications, this Series is IP67 rated and built to be highly responsive and long-lasting, even when used in the harshest of environments.

Features.

Snap in type terminal, directly mounted in PCB.

Output terminal can be also used as jumper leads.

Through hole terminal with plastic cover available.

Two pin terminal Low profile

Spec.

Model No.		TS-C017
Switch Rating		50mA DC 12V
Operation Travel		0.2±0.1mm
Operation Tpye		Momentary
Operation Force		160/180/250 gf
Operation Life		300,000 Cycles
Contact Resistance		≤100mΩ max
Insulation Resistance		≥100MΩ/m DC 250V
Dielectric Strength		AC 250V/m 50Hz
Operation Temperature		-30℃ to + 85℃
Operation Humidity		25-85% RH
Solder Ability		260±5℃ for 3 seconds

Reference.

DIP Thru Hole SMT Tact Switch , Momentary Tactile Switch For Industrial Electronics
