Thru Hole Terminal Silent Tactile Switch With Multiple Actuator Options

Name: Thru Hole Terminal Silent Tactile Switch With Multiple Actuator Options
Brand: BZCN
Price: 1 USD

China Thru Hole Terminal Silent Tactile Switch With Multiple Actuator Options wholesale

Brand Name : BZCN

Model Number : TS-F003

Certification : SGS

Place of Origin : China

MOQ : 1000 pcs

Price : Negotiable

Payment Terms : L/C, T/T, Western Union, MoneyGram

Supply Ability : 10000000 pcs per week

Delivery Time : 5 days

Packaging Details : 1000 pcs per bag

Press : Vertical

Operation : Momentary

Rating : 50mA

Voltage : 12V

Terminal : SMD / DIP

Pin No. : 5 pins

Contact Now

white button 12 mm thru hole terminal tactile switch with Multiple actuator options

12mm x 12mm surface mount tactile switch has an available earth ground terminal option, reliable dome contact technology, and strong tactile feedback. There are two actuator height options and three operating force options to choose from. This switch comes in a gull wing termination. There is a long life option for this switch as well.

Some of the markets for this switch include computer/servers/peripherals, medical equipment, testing/instrumentation, consumer electronics, audio/visual and telecommunications.

Feature.

Reflow solderable.

With earth anti ESD ground terminal.

Packing in tape reel available.

Spec.

Model No.		TS-F003
Terminal Type		DIP
Switch Rating		50mA DC 12V
Operation Travel		0.2±0.1mm
Operation Tpye		Momentary
Operation Force		160/180/250 gf
Operation Life		300,000 Cycles
Contact Resistance		≤100mΩ max
Insulation Resistance		≥100MΩ/m DC 250V
Dielectric Strength		AC 250V/m 50Hz
Operation Temperature		-30℃ to + 85℃
Operation Humidity		25-85% RH
Solder Ability		260±5℃ for 3 seconds

Drawing.

Thru Hole Terminal Silent Tactile Switch With Multiple Actuator Options
